UL 600V XLPE/PVC TC-ER Tray Cable Product Launch

Posted by Connections Systems on September 06, 2018 9:08:43 AM

UL 600V XLPE/PVC TC-ER Tray Cable Product Launch
UL 600V XLPE/PVC TC-ER Tray Cable Product Launch

We are pleased to introduce ShawFlex 600V XLPE/PVC UL TC-ER Control and Power Tray Cable.

ShawFlex 600V XLPE/PVC UL TC-ER Cable meets UL 1277 and FT4/IEEE1202, -40˚C cold bend, SUN RES (for all color jackets), OIL RES I, and Direct Burial requirements, and is suitable for industrial, electrical utility and commercial applications.

ShawFlex UL 600V XLPE/PVC Tray cable has excellent mechanical characteristics, fire safety performance, low-temperature flexibility, UV resistance, and oil resistance combined with high insulation resistance and dielectric strength XLPE insulation, supporting your safe, quick and on-budget electrical installation work.

Benefits and Features:

  • Permitted for exposed run (-ER) use in accordance with NEC, saving installation cost and time
  • Passed rigorous FT4/IEEE1202 flame test
  • SUN RES is available for all color jackets, meeting customers’ requirements without sacrificing performance.
  • Great low-temperature performance for confident cold-weather installation
  • XLPE insulation for a high level of safety and reliability
  • Robust physical protection for both direct burial and exposed run installation
  • Increased durability and reliability in specific industrial environments with OIL RES I approval
  • Available in full range of conductor sizes and conductor counts with all noted approvals for your convenience

Based on the National Electrical Code (NEC), if UL type Tray (TC) cables comply with additional crush and impact test requirements for Metal Clad (MC) cable, UL permits the manufacturer to add an “-ER” (Exposed Run) suffix to the basic listing printed on the cable,

UL TC-ER cables provide an economic solution for electrical engineers and contractors to minimize installation costs without compromising on quality and safety. Cable with TC-ER can be used with no set length limitations between cable trays, and between cable trays and utilization equipment or devices[i]. In this case, using the -ER rated cable can provide significant cost savings vs armored cable (Type MC)[ii], or TC with extended conduit/tray lengths.

The product is supported by ShawFlex’s usual:

  • Comprehensive catalog of standard cable constructions
  • Custom engineered cable design, color-codes, and qualification
  • Short lead time, custom lengths, and low minimum order quantity
  • Reliable delivery and dependable quality

Learn more about all of our ShawFlex wire and cable products by visiting our website or downloading the data sheets for our ShawFlex 600V XLPE/PVC UL TC-ER Control and Power Tray Cables by selecting the images below:

Visit our new Website



[i] as long as the requirements in NEC 336.10.(7) are met
[ii] otherwise required for extensions over 6 feet (1.8m) from the cable tray

FEATURES & BENEFITS

UL TC-ER, HELICAL COPPER TAPE SHIELDED, CONTROL, XLPE/PVC, 600V

UL TC-ER, LONGITUDINAL CORRUGATED COPPER TAPE SHIELDED, CONTROL, XLPE/PVC, 600V

XLPE_PVC UL Tray, TC-ER, power & control, IEEE 1202, 600V_02_DOWNLOAD_IMAGE Data_sheet_UL_TRAY_TC_ER_SHIELDED_HC_CONTROL_XLPE_PVC_XHHW_2_600V_Letter_ENG_01_DOWNLOAD_IMAGE Data_sheet_UL_TRAY_TC_ER_SHIELDED_LC_CONTROL_XLPE_PVC_XHHW_2_600V_Letter_ENG_01_DOWNLOAD_IMAGE



UL TC-ER, SHIELDED, VFD, XLPE/PVC, 600V

UL TC-ER, UNSHIELDED, POWER, XLPE/PVC, 600V

UL TC-ER, UNSHIELDED, CONTROL, XLPE/PVC, 600V

Data_sheet_UL_TRAY_TC_ER_VFD_XLPE_PVC_XHHW_2_Letter_ENG_01_DOWNLOAD_IMAGE Data_sheet_UL_TRAY_TC_ER_POWER_XLPE_PVC_XHHW_2_600V_Letter_ENG_01_DOWNLOAD_IMAGE Data_sheet_UL_TRAY_TC_ER_UNSHIELDED_CONTROL_XLPE_PVC_XHHW_2_600V_Letter_ENG_01_DOWNLOAD_IMAGE
